Size:2”-4” CWP：6000-20000Psi Temperature rate: -29--+121℃ Service： Std. or H2S Standard: API 16C or NACE MR 0175
Tee
Size:2”-4”
CWP：6000-20000Psi
Temperature rate: -29--+121℃
Service： Std. or H2S
Standard: API 16C or NACE MR 0175
Technical Paremetes
Size | Connection | Pressure Class（Psi） | Service |
2” | Fig 1502/2002 MxFxF | 15000/20000 | STD |
2” | Fig 1502/2002 MxMxF | 15000/20000 | STD |
2” | Fig 1502/2002 FxFxM | 15000/20000 | STD |
2” | Fig 1502/2002 FxFxF | 15000/20000 | STD |
2” | Fig 1502/2002 MxMxM | 15000/20000 | STD |
2” | Fig 1502/2002 FxMxM | 15000/20000 | STD |
3” | Fig 1502/2002 MxFxF | 15000/20000 | STD |
3” | Fig 1502/2002 MxMxF | 15000/20000 | STD |
3” | Fig 1502/2002 FxFxM | 15000/20000 | STD |
3” | Fig 1502/2002 FxFxF | 15000/20000 | STD |
3” | Fig 1502/2002 MxMxM | 15000/20000 | STD |
3” | Fig 1502/2002 FxMxM | 15000/20000 | STD |
4” | Fig 1502 MxFxF | 15000 | STD |
4” | Fig 1502 MxMxF | 15000 | STD |
4” | Fig 1502 FxFxM | 15000 | STD |
4” | Fig 1502 FxFxF | 15000 | STD |
4” | Fig 1502 MxMxM | 15000 | |
4” | Fig 1502 FxMxM | 15000 |
Note：1.FIG1002 and 602 from 2”to 4”products can be available.
2.H2S service from 6000 to 15000PSI can be available.
